ItalSens Metal Disc Ultramicroelectrodes

A metallic ultramicroelectrode in a glass coating

Ultramicroelectrodes usually show a high current density due to their diffusion profile, which leads to an increased mass transport to the electrode’s surface. Furthermore, they reach steady state conditions in short time periods compared to macroelectrodes.

Each ultramicroelectrode is supplied with a silicone O-ring, ensuring a secure fit on a plastic component at the top of the electrode body. The adjustable O-ring allows users to customize the electrode depth within an electrochemical cell by rolling it to different positions. The electrode is equipped with a brass rod contact for convenient connection, facilitating easy attachment using a standard crocodile clip.

ItalSens provides the following material and disc diameter options:

• Au, 10 µm, 1 unit (ref. IS-10UM.AU.WE.1)

• Au, 10 µm, 3-pack (ref. IS-10UM.AU.WE.3)

• Au, 25 µm, 1 unit (ref. IS-25UM.AU.WE.1)

• Au, 25 µm, 3-pack (ref. IS-25UM.AU.WE.3)

• Pt, 10 µm, 1 unit (ref. IS-10UM.PT.WE.1)

• Pt, 10 µm, 3-pack (ref. IS-10UM.PT.WE.3)

• Pt, 25 µm, 1 unit (ref. IS-25UM.PT.WE.1)

• Pt, 25 µm, 3-pack (ref. IS-25UM.PT.WE.3)

Electrode active material : Platinum, Gold Electrode type : Working Electrode Brand : ItalSens Electrode (inner) diameter : 10 µm, 25 µm Body / coat material : Glass WE geometric area : 79 µm², 491 µm² Length : 80 mm Outer diameter : 4 mm Possible analytes : naphthol, dopamine, metals, para-aminophenol, arsenic, metal complexes Possible applications : Electrolysis, Modification with biomolecules, Electrodeposition, Detection of redox active species Quantity : 1 unit
